HX Series Heavy Vibrating Screen

Model	Sieve layer	Sieve area (m²)	Mesh size (mm)	Max. feeding size (mm)	>Processing capacity (m³/h)	Vibrating Frequency (r/min)	Double amplitude (mm)	Motor power (kw)	Sieve obliquity (°)	Sieve specification (mm)	>Dimensions (L×W×H) (mm)
2YK1225	2	6	4-50	200	8-60	800-970	8	6P 5.5KW	20	1200×2500	2930×1860×870
3YK1225	3	9	4-50	200	10-70	800-970	8	6P 5.5KW	20	1200×2500	3070×1860×1210
2YK1230	2	7.2	4-50	200	12-78	800-970	8	6P 7.5KW	20	1200×3000	3430×1860×870
3YK1230	3	10.8	4-50	200	13-80	800-970	8	6P 7.5KW	20	1200×3000	3570×1860×1210
2YK1237	2	8.88	4-50	200	15-86	800-970	8	6P 7.5KW	20	1200×3700	4050×1860×870
3YK1237	3	13.32	4-50	200	16-90	800-970	8	6P 7.5KW	20	1200×3700	4270×1860×1210
2YK1535	2	10.5	5-50	200	20-125	800-970	8	6P 11KW	20	1500×3500	4120×2210×1230
3YK1535	3	15.75	5-50	200	21-125	800-970	8	6P 11KW	20	1500×3500	4360×2210×1610
2YK1545	2	13.5	5-50	200	22-150	800-970	8	6P 11KW	20	1500×4500	5120×2210×1230
3YK1545	3	20.25	5-50	200	22-150	800-970	8	6P 15KW	20	1500×4500	5360×2210×1610
4YK1545	4	27	5-50	200	22-155	800-970	8	6P 15KW	20	1500×4500	5930×2210×2060
2YK1548	2	14.4	5-50	200	22.5-162	800-970	8	6P 11KW	20	1500×4800	5420×2210×1230
3YK1548	3	21.6	5-50	200	22.5-162	800-970	11	6P 15KW	20	1500×4800	5660×2210×1610
4YK1548	4	28.8	5-50	200	22.5-162	800-970	8	6P 18.5KW	20	1500×4800	6230×2210×2060
2YK1848	2	17.28	5-80	200	25-206	750	8	6P 18.5KW	20	1800×4800	5420×2550×1420
3YK1848	3	25.92	5-80	200	32-276	750	8	6P 18.5KW	20	1800×4800	5660×2550×1780
4YK1848	4	34.56	5-80	200	32-285	750	8	6P 22KW	20	1800×4800	6290×2550×2160
2YK1854	2	19.44	5-80	200	32-312	800-970	8	6P 22KW	20	1800×5400	5960×2550×1420
3YK1854	3	29.16	5-80	200	32-312	800-970	8	6P 22KW	20	1800×5400	6260×2550×1780
4YK1854	4	38.88	5-80	200	32-336	800-970	8	6P 22KW	20	1800×5400	6830×2550×2160
2YK2160	2	25.2	5-100	200	50-475	970	8	6P 30KW	20	2100×6000	6720×2840×1530
3YK2160	3	37.8	5-100	200	50-475	970	8	6P 30KW	20	2100×6000	7030×2840×1910
4YK2160	4	50.4	5-100	200	50-497	970	8	6P 37KW	20	2100×6000	7300×2840×2380
2YK2460	2	28.8	5-100	200	65-550	970	8	6P 30KW	20	2400×6000	7020×3140×1530
3YK2460	3	43.2	5-100	200	70-620	970	8	6P 37KW	20	2400×6000	7300×3140×1910
4YK2460	4	57.6	5-100	200	80-680	970	8	6P 45KW	20	2400×6000	7600×3140×2380
2YK2870	2	39.2	5-100	200	120-680	750	8	8P 22×2KW	20	2800×7000	7600×4320×1620
3YK2870	3	58.8	5-100	200	180-720	750	8	8P 22×2KW	20	2800×7000	7800×4320×2120
2YK3072	2	43.2	5-100	200	200-700	750	8	8P 22×2KW	20	3000×7200	7800×4520×1750
3YK3072	3	64.8	5-100	200	230-800	750	8	8P 22×2KW	20	3000×7200	8000×4520×2300
